Inert Gas Blanketing Regulator

About The Product

A blanketing regulator is a self-operated pressure control device designed to maintain a constant low-pressure inert gas (typically nitrogen) blanket over stored liquids. It protects tanks from air ingress, moisture contamination, and explosion hazards while minimizing product loss.

This helps prevent outside air, moisture, and contaminants from entering the tank, protecting the stored product from oxidation, spoilage, or chemical reaction. It also reduces evaporation losses and lowers the risk of fire or explosion when handling flammable liquids. Blanketing regulators are commonly used in chemical plants, oil storage facilities, pharmaceutical industries, food processing plants, and other applications where product quality and tank safety are important. Since they operate without external power, they are reliable, economical, and easy to maintain.

Safety Relief Valve
Model Number: VYN-BRS Series

Features

  • Stable low-pressure control
  • Bubble-tight shut-off
  • Compact and maintenance-friendly design
  • Suitable for hazardous and solvent storage tanks

Technical Specifications

  • Type:Self-operated, Pilot Operated diaphragm sensing
  • Control Pressure Range:5 mbar(g) to 25-30 mbar(g)
  • Inlet Pressure Range:Up to 6 barg (higher on request)
  • Accuracy: ±15% of set pressure
  • Flow Capacity: Designed as per tank inbreathing requirement
  • Body Material:CS, SS 304, SS 316, SS 316L
  • Trim & Internals:SS 304 / SS 316 / Hast Alloy C/ Monel / Inconel
  • Seat Material: Nitrile / PTFE / FKM (as per application)
  • Diaphragm:Nitrile with PTFE backup / EPDM
  • End Connections: Screwed / Flanged (ANSI / DIN)
  • Sizes Available: 15 NB to 50 NB (Higher Sizes on request)
Safety Relief Valve
Model Number: VYN-BRP Series

Application

Chemical
Pharmaceuticals
Oil & Gas
Speciality Chemicals
OEMs
